• Standard 3.6V DC low-voltage drive, compatible with special lithium batteries for water meters.
• Ultra-low power consumption design: micro-ampere level in standby mode, low power consumption for single valve operation.
• Small and compact structure, suitable for the internal space of valve-controlled water meters.
• Stable torque, with self-locking and limit protection, strong water pressure resistance.
• Stable operation, low noise and reliable valve action.
• Long service life, high matching degree with water meter control boards, simple driving and strong compatibility.
The main functions of DC 3.6V actuator is to receive signals from the water meter main control, complete automatic valve opening and closing, and automatically cut off water for protection in case of arrears or abnormal conditions. It supports remote valve control and enables intelligent water management.
| 1.Rated voltage | 3.6V |
| 2.Working voltage | 2.5-5V |
| 3.At noload current | <=100mA (temperature 23℃) |
| 4.Locked-rotor current | ≤520mA (030P motor) |
| 5.Torque | ≥2NM（20001） |
| 6.Switching time | ≤8s（20001） |
| 7.Reduction ratio | 20001(DN15-20) |
| 8.Definition of line sequence (can be customized) |
I. Gray (open) II. Yellow (COM) III. Purple (close) IV. Red (positive) V. Black(negative) |
| 9. Waterproof grade | IP67 |
What should I do if the valve gets stuck and the actuator triggers locked-rotor current?
A: The actuator’s locked-rotor current (≤520 mA) is designed with overload protection. When jamming occurs, the water meter control board will detect the overcurrent signal and automatically cut off power to the actuator, preventing motor burnout. After troubleshooting the jamming (e.g., removing impurities in the valve), the actuator can resume normal operation.
