The Water Meter Valve Actuator Controller features stable electrical performance and reliable actuation output, with standardized technical parameters as follows
| Item | Specification |
| Rated Operating Voltage | 3.6V |
| Operating Voltage Range | 2.5–5V |
| No‑load Operating Current (@ Rated Voltage) | ≤25mA |
| Plug‑in Operating Current (@ Rated Voltage) | Approx. 550mA (320 motor) |
| Output Torque (@ Rated Voltage) | ≥1.8N·m |
| On/Off Response Time (@ Rated Voltage) | ≤8s |
| Metering Ratio | 1500:1 (applicable for DN15‑20) |
| Waterproof Rating | IP0 |
The Water Meter Valve Actuator Controller uses a 5 pin wiring configuration with clear signal definition for easy installation and commissioning:
1. White wire: Top switch signal (valve open)
2. Blue wire: Common terminal for signal
3. Yellow wire: Top switch signal (valve close)
4. Red wire: Top position terminal
5. Black wire: High/low level terminal
Note: Valve open/close positioning may reverse due to differences in customer installation orientation and application scenarios. Final open/close logic shall be confirmed by customers based on actual installation and operating conditions.
With stable parameter performance and standardized wiring design, the Water Meter Valve Actuator Controller delivers reliable control for water meter valve actuation in residential and commercial metering systems.
What water meter diameters is this Water Meter Valve Actuator Controller compatible with?
It is specially designed for DN15 and DN20 water meters, with a fixed metering ratio of 1500:1 to match the metering and control requirements of these standard calibers.
What does the waterproof rating of 0 (IP0) mean for actual use?
IP0 indicates the actuator has no special waterproof or dustproof protection. It is only suitable for installation in indoor, dry, and non‑immersion environments; avoid direct water contact, rain, or high‑humidity open air.
