Ultrasonic water meter electric actuator is a valve control driving component specially designed for non-magnetic metering ultrasonic water meters. Ultrasonic water meter electric actuator adopts a low-power, high-precision gearbox and motor structure, working with the main control to realize smooth valve opening, closing and self-locking.
With compact size, quiet operation and strong water pressure resistance, Ultrasonic water meter electric actuator is specially designed for battery-powered ultrasonic water meters. It can realize functions such as automatic shut-off for arrears, remote control and timed water control, ensuring accurate metering and stable, reliable water control.
| Voltage | 3.6V | Operable voltage | 2.5-5V |
| Locked-rotor current | 550mA | Operating Current | ≤25mA |
| On (Off) Time | ≤13s | ||
| Torque:≥2.5NM | |||
| Reduction ratio | 3500:1 | Waterproof rating | IP67 |
| Definition of line seq uence: | |||
| Red: | positive | Black: | negative |
| Blue: | Open | White: | COM |
| Yellow: | Close | ||
Q: If the valve jams and triggers locked-rotor current (550 mA), will it damage the ultrasonic water meter’s main control board?
A: No. The actuator’s built-in overcurrent protection cuts off power within 2s of detecting locked-rotor current, preventing excessive current from flowing to the main control board. After clearing the jam (e.g., removing sediment in the valve), the actuator resumes normal operation once the main control board reissues a signal.
Q: Can the wiring sequence be customized to match our existing ultrasonic water meter production line?
A: Yes. We support full customization of wire color, function definition, and wire length. Simply provide your main control board’s pin diagram (e.g., which pin corresponds to "valve open"), and we will produce the actuator with pre-matched wiring—directly compatible with your production line, no manual reworking needed.
