The core function of waterproof dc water meter actuator is to block water flow and moisture through its sealed structure, preventing internal circuits or mechanical components from being damaged by moisture, thereby directly extending its service life in water-exposed scenarios.
| Voltage | 3.6V | Operable voltage | 2.5-5V |
| Locked-rotor current | 450mA | Operating Current | ≤25mA |
| On (Off) Time | ≤10s(2400:1) | Output Torque | ≥1.8N.m(2400:1) |
| On (Off) Time | ≤20s(5000:1) | Output Torque | ≥4.5N.m(5000:1) |
| Reduction ratio | 2400:1(DN15-20) | Waterproof rating | IP67 |
| Reduction ratio | 5000:1(DN25) |
1.The White and the Yellow wire is the position switch signal
2.The Blue wire is the common terminal for the position signal
4. Red (positive) +
5. Black (negative)-
The fully open and fully closed positions can be customized according to customer requirements.
An Actuator with Excellent Sealing Performance
Q: What is the core function of the KY-06 Waterproof DC Water Meter Actuator?
A: Its core function is to block water flow and moisture through a sealed structure, which prevents internal circuits or mechanical components from being damaged by moisture, thereby directly extending the product's service life in water-exposed scenarios.
Q: What is the significance of the IP67 waterproof rating for this actuator?
A: IP67 waterproof rating means the waterproof dc water meter actuator can completely prevent dust intrusion and be immersed in water for a short time, making it suitable for various water-exposed or wet scenarios, ensuring stable operation without being damaged by moisture.
Q: How to choose the right reduction ratio (2400:1 or 5000:1) for different pipelines?
A: Choose according to pipeline DN specifications and torque needs: 2400:1 (applicable to DN15-20 pipelines) with output torque ≥1.8N.m and on/off time ≤10s; 5000:1 (applicable to DN25 pipelines) with output torque ≥4.5N.m and on/off time ≤20s.
Q: Can the fully open and fully closed positions of the KY-06 actuator be adjusted?
A: Yes. The fully open and fully closed positions can be customized according to customer requirements, which can better adapt to different water supply pipeline installation and usage scenarios.
Q: What is the utility model patent certificate of this actuator?
A: The company has obtained the utility model patent certificate for "An Actuator with Excellent Sealing Performance", which proves the product's outstanding sealing and waterproof performance, and also reflects the company's technological innovation strength.
