The opening and closing of the valve are controlled by changing the polarity of the wiring: the valve closes when the red wire is connected to the positive electrode and the black wire to the negative electrode, and opens when the polarity is reversed. Water meter gate valve gear motor, on the other hand, uses the air source pressure acting on the pneumatic diaphragm to drive the valve stem movement, realizing the opening and closing operation of the valve. When the air source pressure disappears, the spring force returns the valve stem to its original position.
| Voltage | 3.6V | Operable voltage | 2.5-5V |
| Locked-rotor current | 450mA | Operating Current | ≤25mA |
| On (Off) Time | ≤13s | Rated thrust | >15Kg |
| Time for no-load 6mm stroke under rated operating voltage: approximately 60 seconds | |||
| Reduction ratio | 1000:1 | Waterproof rating | 0 |
| Definition of line seq uence: | |||
| Red | positive | Black | negative |
Good adjustability: Gate valves are inherently suitable for throttling, and when used with an actuator, fine adjustment can be achieved.
Good sealing performance: The valve stem pressure ensures a tight seal between the sealing surfaces, resulting in high durability.
Wide applicability: Suitable for medium to low pressure applications, ranging from low to high pressure.
